SPECIFICATIONS

Brand Name: DOKIO
Certification: CE
Flexible Solar Panel: Yes
Foldable Solar Panel: Yes
High-concerned chemical: None
Material: Monocrystalline Silicon
Maximum Power Current (Imp): 6.1A
Maximum Power Voltage(Vmp): 18.00V
Maximum Power(Pmax): 100W±3%
Maximum System Voltage: DC1000V
Model Number: FFSP-97M
Nominal Capacity: None
Nominal Operating Cell Temp.(NOCT): -45 to 80℃
Number of Cells: 36
Number of Panels: 1
Open-Circuit Voltage (Voc): 20.5V
Origin: Mainland China
Short-Circuit Current (Isc): 6.35A
Size: 48*66*1.2cm
Type: Solar Panel
is_customized: Yes


Dear customer, due to product upgrade,the size and weight of the product you receive may be different.


Product Description:


Model:FFSP-97M
Material:Monocrystalline silicon
Maximum Power(Pmax):97W±3%
Maximum Power Voltage(Vmp):18.00V
Maximum Power Current (Imp):6.1A
Open-Circuit Voltage (Voc):20.5V
Short-Circuit Current (Isc):6.35A
Nominal Operating Cell Temp.(NOCT):-45 to 80℃
Maximum System Voltage: DC1000V
Foldable Dimension:48*66*1.2 cm
Expansion Dimension:96*66*0.6 cm
Net Weight: 2.4 kg
Package Weight:3.4kg
Package Size:77*50.5*4 cm
Package List:
1*97W Flexible Foldble Solar Panel，
1*3M wire,
1*10A 12Vcontroller,
1*English User Manual




Model:FFSP-150M
Material:Monocrystalline silicon
Maximum Power(Pmax): 150W±3%
Maximum Power Voltage(Vmp):18.00V
Maximum Power Current (Imp):8.89A
Open-Circuit Voltage (Voc): 22.50V
Short-Circuit Current (Isc):9.14A
Nominal Operating Cell Temp.(NOCT):-45 to 80℃
Maximum System Voltage: DC1000V
Foldable Dimension:53*49*2.8 cm
Expansion Dimension:195*53*0.6 cm/77*21*0.2 inch
Net Weight:3.3kg
Package Weight:4.5kg
Package Size: 63*50.5*4 cm
Package List:
1*150W Flexible Foldble Solar Panel，
1*3M wire,
1*10A 12Vcontroller,
1*English User Manual



Model:FFSP-195M
Material:Monocrystalline silicon
Maximum Power(Pmax): 195W±3%
Maximum Power Voltage(Vmp):18.00V
Maximum Power Current (Imp):11.12A
Open-Circuit Voltage (Voc): 20.5V
Short-Circuit Current (Isc):11.36A
Nominal Operating Cell Temp.(NOCT):-45 to 80℃
Maximum System Voltage: DC1000V
Foldable Dimension:49*67*2.8 cm
Expansion Dimension:195*67*0.6 cm/77*26*0.2 inch
Net Weight:4.4kg
Package Weight:5.6kg
Package Size:77*50.5*4 cm
Package List:
1*195W Flexible Foldble Solar Panel
1*3M wire,
1*20A 12Vcontroller,
A total of 4M long cable. With alligator clips，
1*English User Manual




Model:FFSP-295M
Material:Monocrystalline silicon
Maximum Power(Pmax): 295W±3%
Maximum Power Voltage(Vmp):18.00V
Maximum Power Current (Imp):16.67A
Open-Circuit Voltage (Voc): 20.50V
Short-Circuit Current (Isc):16.92A
Nominal Operating Cell Temp.(NOCT):-45 to 80℃
Maximum System Voltage: DC1000V
Foldable Dimension:49*95*2.8 cm
Expansion Dimension:196*95*0.6 cm/77.2*37*0.2 inch
Net Weight:6.9kg
Package Weight:8.1kg
Package Size:105*50.5*4 cm
Package List:
1*295W Flexible Foldble Panel
A total of 4M long cable. With alligator clips，
1*20A 12Vcontroller
1*English User Manual

(The above data is based on the laboratory standard test environment)

For field connections,use minimun No.12AWG copper wires insulated for a minimum 90℃

Standard Test Conditions:

AM=1.5 IRRADIANCE=1000W/m2 Temp.=25℃
(The size is manually measured and there is a certain error.）
Controller support lead-acid,lithium ions and LiFePO4 battries.
